For Cylinder Cell and Pouch Cell Battery Electrolyte Diffusion Vacuum Chamber machine
Item No.: WV-TQJ-300
Manufacture: Guangdong, China
Delivery Time: 7-20days
Customizable: Yes
Products
Products DETAILS
For Cylinder Cell and Pouch Cell Battery Electrolyte Diffusion Vacuum Chamber machine
For Cylinder Cell and Pouch Cell Battery Electrolyte Diffusion Vacuum Chamber machine
Product Features
The equipment is mainly used to absorb electrolyte when injecting liquid into soft-pack batteries and cylindrical batteries under vacuum conditions, so that it can be more fully mixed with the electrodes. The whole set of equipment is made of high-quality electronic components and materials, suitable for batteries of various sizes, easy to operate, high production efficiency, and is an ideal multi-functional equipment for laboratories.1. The vacuum remains stable and the vacuum degree will not drop too much.
2. The multi-stage cycle operation function makes the electrolyte more fully integrated.
3. The changes in the cabin can be observed through the perspective window.
4. The upper chamber is driven by a cylinder and guided by four linear guide bushings, which can be flexibly moved up and down and accurately guided to ensure the sealing requirements of the product.
5. Suitable for batteries of various sizes, simple and convenient adjustment.
6. The split design of the main unit and the control box enables the machine to work in the glove box and on the production line.
7. Easy to operate, beautiful appearance, small size and light weight.
Specification
|
POUCH CELL LAB EQUIPMENT
|
|
|
Item Name
|
Battery Electrolyte Diffusion Vacuum Chamber machine WV-TQJ-300
|
|
Chamber Material
|
Aluminum that is anti- corrosion, and structure is stable.
|
|
Diffusion time
|
0 ~ 9999s
|
|
Vacuum degree
|
Can reach -90KPa( vacuum pump should be self-supplied by the buyer).
|
|
Voltage
|
220V/50Hz
|
|
Power
|
50W
|
|
Compressed air source
|
0.5MPa~0.7MPa
|
|
Working temperature
|
-20~40℃
|
|
Dimension of the inside chamber
|
L355mm*W256mm*H325mm
|
|
Moving part of executive chamber
|
About L510mm*W300mm*H820mm
|
|
Controller Dimension
|
L450mm*W370mm*H260mm
|
