Injection Machine 16 station 60 series supercapacitor battery
Functional description:
Mainly used for Dia60 supercapacitors, quantitative injection of products in the glove box, injection accuracy is 1.2% of the injection volume, and the maximum injection volume is 260g.
It adopts a double-row design, and eight products in each row are vacuumed, injected, and stationary at the same time.
It includes a glove box and purification system, high vacuum and filtration system, electrolyte storage buffer system, quantitative injection system, production capacity 3ppm, compatible with the full range of products.
Machine Name: WV-ZYJ
Specif ication and model:
Machine dimensions: 4600x1300x2700mm
Machine speed: 3pcs/min;(12 stations can be customized)
Voltage:AC 220V
Weight: 1120kg
Power: 3KW
Product diameter:Dia60
Product height: 52~138mm
Applications: supercapacitor 60series
Mainly used for Dia60 supercapacitors, quantitative injection of products in the glove box, injection accuracy is 1.2% of the injection volume, and the maximum injection volume is 260g.
It adopts a double-row design, and eight products in each row are vacuumed, injected, and stationary at the same time.
It includes a glove box and purification system, high vacuum and filtration system, electrolyte storage buffer system, quantitative injection system, production capacity 3ppm, compatible with the full range of products.
Specif ication and model:
Machine dimensions: 4600x1300x2700mm
Machine speed: 3pcs/min;(12 stations can be customized)
Voltage:AC 220V
Weight: 1120kg
Power: 3KW
Product diameter:Dia60
Product height: 52~138mm
Applications: supercapacitor 60series
