Laser Welding Machine Upper and Lower Collect Current supercapacitor battery

Functional description:

Mainly used for laser welding of Dia60 supercapacitors, cathode and anode tabless connecting pieces, and compatible with 3000F, 2000F, 1500F, 1200F, and 650F series. The machine adopts a two-station rotation 180° welding and jelly roll installation working mode at the same time, and a double jelly roll clamping design to reduce product clamping time, with a production capacity of 3-4ppm. The machine can also be used for cylindrical tabless lithium batteries, cathode and anode tabless laser welding production.

Specif ication and model: WV-JGH01
Machine dimensions: 2900x1500x2000mm
Machine speed: 3~4pcs/min
Voltage: 380V
Weight: 660kg
Power: 2KW
Product diameter: Dia60
Product height: 36~123mm
Applications: supercapacitor 60series
