Energy-saving feedback series-capacity cabinet grading machine for cylindrical cell 512 channels 3A
Manufacture: Guangdong, China
Delivery Time: 7-20days
Customizable: Yes
Products
Products DETAILS
Energy-saving feedback series-capacity cabinet grading machine for cylindrical cell 512 channels 3A
Energy-saving feedback series-capacity cabinet grading machine for cylindrical cell 512 channels 3A
Specification
Power Supply
3-phase 5-wire AC 380V ±10% / 50Hz
Dimensions (L×W×H)
1622 × 859 × 1840 mm
Operating Power
≤ 9.6 kW
Channels
512 channels (system total)
Battery Specifications
Diameter: 18–32 mm; Length: 65–180 mm
Diameter: 32–60 mm; Length: 80–160 mm
Charge/Discharge Voltage
DC 0 mV – 4.5 V / DC 2 V – 4.5 V
Constant Voltage Range
DC 2 V – 4.5 V
Voltage Measurement
DC 0 V – 5 V
Charge/Discharge Current
10 mA – 3 A
Voltage Accuracy
±(0.5‰ rdg + 0.5‰ FS)
Voltage Resolution
1 mV
Current Accuracy
±(0.5‰ rdg + 0.5‰ FS)
Current Resolution
1 mA
Time Accuracy
≤ ±0.1%
Charge/Discharge Modes
CC, CV, CC-CV / CC, CP, CR
Charge Cutoff Conditions
Voltage, Current, Time, Capacity, -ΔV
Discharge Cutoff Conditions
Voltage, Time, Capacity
Process Setup
Up to 64 steps, 256 cycles
Control Method
PC-controlled; Cabinet-level control with scanning system
Protection Functions
Over-voltage, Under-voltage,
Over-current, Under-current,
Over-capacity, Power-off protection,
Data breakpoint recovery
